Simple, robust, and economical sealing solution
-
Wide range of sizes, materials, and hardness options
-
Resistant to chemicals, temperature, and wear
-
Suitable for static and dynamic sealing
-
FDA and USP Class VI compliant grades available for pharma & food
-
Easy to install and replace
-
Standards: AS568, ISO 3601, DIN, BS, JIS
-
Sizes: Metric & Imperial dimensions, custom sizes available
-
Hardness (Shore A): 40 – 90 depending on application
-
Cross-sections: Standard circular, quad-ring (X-ring), square-ring
-
Materials Available:
-
Elastomers: NBR, EPDM, Silicone, Viton (FKM), Neoprene
-
High-Performance Polymers: PTFE, FFKM (Perfluoroelastomer), Kalrez® equivalents
-
Food & Pharma Grades: Platinum-cured Silicone, White EPDM, PTFE-encapsulated O-rings
-
-
Temperature Range:
-
NBR: -30°C to +120°C
-
EPDM: -50°C to +150°C
-
Viton (FKM): -20°C to +200°C
-
Silicone: -60°C to +200°C
-
PTFE: -200°C to +250°C
-
FFKM: up to +325°C
-
-
Pressure Range: Vacuum up to 700 bar (depending on size and application)
-
Chemical Compatibility: Resistant to water, steam, oils, fuels, acids, solvents (material dependent)
-
Compliance: FDA 21 CFR 177.2600, USP Class VI, EC 1935/2004
• Filter housings, cartridge seals, and bag filters
• Sanitary pipe joints and tri-clamp connections
• Hydraulic & pneumatic sealing systems
• Valves, pumps, and compressors
• High-purity pharma and biotech processing
• Aggressive chemical handling and solvent lines
• Aerospace, automotive, and semiconductor applications
